SPECIFICATIONS:
-
- Tonnage = 100
- Stroke = 3″
- Speed (Variable) = 0 – 300 SPM
- Slide Adjustment = 4″
- Shut HT (S.D.A.U.) = 21″
- Bed Area = 48″ L-R x 31″ F-B
- Slide Area = 48″ L-R x 22″ F-B
- Side Window Width = 16″
- Motor = 20 HP
- Electric = 230/480V/60HZ/3PH
- Weight (Approx.) = 33,900 lbs
- Dimensions = 106″ L x 63″ W x 144″ H
EQUIPPED WITH:
-
- Air Clutch and Brake
- Recirculating Lubrication System
- Dual Air Counterbalances
- OEM Minster Control with Wintriss WPC Smart Pac2
- Floor Mounted Operator Console
- Electric Ram Adjust
- Eddy Current Drive
- Eight Point Gibbing
- Tie Rod Construction
- 5″ T-Slotted Bolster Plate (with Center Cutout)
- (4) Isolation Mounts
May be seen under power on our floor
