SPECIFICATIONS:
-
- Tonnage = 30
- Stroke = 2″
- Speed (Variable) = 0 – 350 SPM
- Slide Adjustment = 2″
- Shut HT (S.D.A.U.) = 11″
- Bed Area = 20″ L-R x 19″ F-B
- Slide Area = 20″ L-R x 19″ F-B
- Side Window Width = 7.5″
- Motor = 10 HP
- Electric = 230/460V/60HZ/3PH
- Weight (Approx.) = 8,000 lbs
- Dimensions = 58″ L x 46″ W x 96″ H
EQUIPPED WITH:
-
- Air Clutch and Brake
- Dual Air Counterbalances
- Automatic Recirculating Lubrication System
- Eight Point Gibbing
- T-Slotted Ram
- Tie Rod Construction
- Eddy Current Motor
- 2” T-Slotted Bolster
- (4) Isolation Mounts
May be seen under power on our floor
