SPECIFICATIONS:
-
- Tonnage = 60
- Stroke = 4″
- Speed (Fixed) = 90 SPM
- Slide Adjustment = 2.75″
- Shut Height (S.D.A.U.) = 13″
- Ram Size = 24″ L-R x 14.25″ F-B
- Bed Area = 32″ L-R x 21″ F-B
- Motor = 10 HP
- Electrics = 220/480V/60HZ/3PH
- Weight (Approx.) = 12,000 lbs.
EQUIPPED WITH:
-
- Minster Air Clutch and Brake
- Dual Safety Clutch Valve
- Cieco OSHA PPC1000R Compliant Press Control with Time-Based Brake Monitor with Die Protection
- Recirculating Lubrication System
- Flanged Ram
- 3” Bolster
- (4) Isolation Mounts
May Be Seen Under Power on Our Floor
