SPECIFICATIONS:
-
- Capacity = 60 Ton
- Length of Stroke = 4″
- Strokes Per Minute (Fixed) = 90
- Slide Adjustment = 3″
- Shut Height Over Bolster (SDAU) = 15-1/2″
- Bed Area = 21″ x 32″
- Motor = 10 HP
- Electrics = 220/440/3PH
- Weight = 12,000 lbs.
STAMPTECH’S REMANUFACTURING PROCESS INCLUDES:
-
- Complete Press Teardown
- Cleaning and Inspection of All Parts and Comparing Them to Original Specifications
- Remachining of Crown Bearing Bores, Connection Bores, Gibs Slide and Bolster as Required to Meet Specifications
- Replacement of all Bronze Bushings, Bearings, Oil Seals, Packing and Other Wear Items
- Installation of a New Lubrication System
- Installation of a New Pneumatic System
- Upgrading to the latest Safety Requirements
- Retention of a Permanent Record for the life of the Remanufactured Equipment
- 1 Year Warranty
- New Manuals and Wiring Diagrams
EQUIPPED WITH:
-
- New O.E.M. Minster Air Clutch and Brake Components
- New Energy Efficient Motor
- New OSHA Compliant Cieco MPPC 1100R Press Control Resolver Based
- All New Electrics
- New Recirculating Lubrication System
- Flanged Ram
- Bronze Gibbs
- New Bolster Plate to Your Specifications
- Press Mounts
ONE YEAR WARRANTY:
-
- May Be Seen Under Power on our Floor
