SPECIFICATIONS:
-
- Tonnage = 35
- Stroke = 2.758″
- Speed (Variable) = 40-120 SPM
- Full Tonnage Off Bottom = 0.126″
- Slide Adjustment = 2.167″
- Shut HT (S.D.A.U. over Bolster) = 8.668″
- Bed Area = 31.52″ L-R x 15.76″ F-B
- Slide Area = 14.18″ L-R x 9.85″ F-B
- Motor = 5 HP
- Electric = 230/480V/60HZ/3PH
- Weight (Approx.) = 7,000 lbs
- Dimensions = 50″ L x 37″ W x 100″ H
EQUIPPED WITH:
-
- Air Clutch and Brake
- Cieco Control with Time-based Brake Monitor
- Air Counterbalances
- Hydraulic Overload
- Energy Efficient Motor
- T-Slotted Ram
- 3″ T-Slotted Bolster
- (4) Isolation Mounts
May be seen under power on our floor
